G4-59

Cylinder head assembly
A rebuilt cylinder head assembly that includes all components shown in photograph starts at $1,750 depending on the condition of your cylinder head you send in to be rebuilt. If you don't have a core, we can provide one for $650. Assembled and machined when ordered; production time 4-6 weeks depending on que. Call or Email our service department for details.

1G prefix

1

$1750.00

G4-436

Cylinder head assembly
A rebuilt cylinder head assembly that includes all components shown in photograph starts at $1,350 depending on the condition of your cylinder head, valves and seats that you send in. If you need a core, one can be purchased for $395. Assembled and machined when ordered; production time 6 weeks depending on machining que. Email our service department for details.

2G prefix

1

$1375.00

48G201

Cylinder head assembly
A rebuilt cylinder head assembly that includes all components shown in photograph starts at $1,350 depending on the condition of your cylinder head, valves and seats that you send in. If you need a core, one can be purchased for $395. Assembled and machined when ordered; production time 6 weeks depending on machining que. Email our service department for details.

1500

1

$1375.00

1

1A2116

Guide, intake

to E11000

4

$4.76

11G313

Guide, intake

E11001-

4

$6.38

2

1G1332

Guide, exhaust

to E11000

4

$5.49

11G193

Guide, exhaust

E11001-

4

$6.60

3

6K872

Plug

E11001-

1

$1.41

4

2K8565

Stud, short

to E11000

2

$21.60

51K881

Stud, short

E11001-

2

$2.28

5

6K488

Stud, long

to E11000

2

$23.07

51K893

Stud, long

E11001-

2

$2.71

6

811 0251

Stud

to E11000

3

$18.67

53K531

Stud

E11001-

3

$2.28

7

1G1693

Intake valve

to E11000

4

$54.57

11G310

Intake valve

E11001-

4

$22.34

8

1A2119

Exhaust valve

to E11000

4

$66.22

1H1330

Exhaust valve

E11001-

4

$33.31

9

6K504

Spring set

to E11000

1

$79.06

1G2887

Spring set

E11001-

1

$69.92

10

1G2379

Shroud

All Metropolitans

8

$7.11

12

811 0143

Cup (U)

to E11000

8

$9.53

1A2122

Cup

E11001-

8

$16.48

13

811 0146

Cotter (U)

to E11000

16

$11.72

1K800

Cotter

E11001-

16

$21.60

14

1K372

Circlip

All Metropolitans

8

$3.30

15

2K3451

Stud

to E11000

2

$17.20

FHS2512

Stud

E11001-

2

$3.01

16

1G2075

Rocker shaft, authentic reproduction

to E11000

1

$270.86

11G62

Rocker shaft

E11001-

1

$51.77

17

6K878

Plug

All Metropolitans

1

$25.27

19

ALT-41

Bracket, tapped (U)

to E11000

1

$41.00

1H1419

Bracket, tapped

E11001-

1

$56.74

20

ALT-42

Bracket, plain (U)

to E11000

3

$41.00

1H1420

Bracket, plain

E11001-

3

$40.05

21

2K8567

Spring (U)

to E11000

3

$10.25

6K871

Spring

E11001-

3

$2.28

22

1G1441

Rocker (U)

to E11000

8

$46.85

11G45

Rocker

E11001-

8

$50.30

23

1G2295

Bush

E11001-

8

$6.44

24

ALT-56

Adjusting screw (U)

E11001-

8

$7.33

48G207

Adjusting screw

E11001-

8

$5.06

25

2K8492

Nut

to E11000

8

$6.24

51K1178

Nut

E11001-

9

$1.84

26

2A258

Locating screw

E11001-

1

$4.76

27

2A259

Locating plate

E11001-

1

$6.24

29

2K6804

Washer

All Metropolitans

2

$1.41

30

1A2142

Head gasket

to E11000

1

$228.69

12H60

Head gasket

E11001-

1

$48.69

31

PWN106

Washer

All Metropolitans

11

$1.41

32

2K3799

Nut

to E11000

11

$5.49

51K371

Nut

E11001-

11

$2.56

33

811 0256

Plug (U)

to E11000

1

$16.10

1G2953

Plug (U)

E11001-

1

$8.79

34

1B3664

Washer

E11001-

1

$1.41

35

2A2252

Valve cover (U)

to E11000

1

$67.35

1H1339

Valve cover (U), sandblasted and primed

E11001-

1

$52.71

1H1339b

Valve cover (U), not sandblasted

E11001-

1

$27.50

36

8G615

Cap & cable

All Metropolitans

1

$39.16

37

1A2155

Valve cover gasket

to E11000

1

$18.67

12H37

Valve cover gasket

E11001-

1

$7.70

38

2K8568

Bushing, valve cover cap

All Metropolitans

2

$1.41

39

1A2156

Washer, valve cover cap

All Metropolitans

2

$1.98

40

1B2925

Distance piece or spacer, valve cover cap

All Metropolitans

2

$3.30

41

1A2157

Nut, valve cover cap

to E11000

2

$17.94

2A150

Nut, valve cover cap

E11001-

2

$5.80

42

1G2243

Elbow (U)

All Metropolitans

1

$12.45

43

1G2342

Gasket

All Metropolitans

1

$2.34

44

811 1234

Return pipe (U)

to E11000

1

$67.35

1G2918

Return pipe (U)

E11001-

1

$46.85

45

1G2351

Thermostat housing

All Metropolitans

1

$58.20

46

1A2149

Gasket

All Metropolitans

1

$4.08

47

811 2398

Thermostat, 160 degrees

All Metropolitans

1

$12.09

11G291

Thermostat, 180 degrees

All Metropolitans

1

$12.09

48

3H2006

Spark plug

All Metropolitans

4

$6.33
